Light Gauge Cut To Length Production Line

KINGREAL manufacturer can provide complete coil processing equipment solutions to solve production problems for customers. On the cut-to-length shearing line equipment, KINGREAL will customize the production according to the needs of customers with different specifications, such as Light Gauge Cut To Length Production Line.

Send Inquiry    PDF DownLoad

Product Description

Video About Light Gauge Cut To Length Line:

Description Of Light Gauge Cut To Length Production Line

The KINGREAL Light Gauge Cut To Length Production Line has advanced automation technology and high-precision processing machinery, which can realize complex processing of various materials (such as stainless steel, iron plate, aluminum plate, hot-rolled steel and cold-rolled steel). Precisely cut materials of different specifications into specified widths, and perform stacking work.



KINGREAL adopts advanced controllers, which can realize automatic control and improve the processing accuracy and reliability of the cut to length line.



It has the characteristics of high production efficiency and reliable quality. And the parameters of the production line can be adjusted according to the needs of customers to meet the different needs of customers.

If you have any questions or doubts about the CTL Machine or other machine, you can contact us at the first time, and KINGREAL is happy to answer for customers.


Working Process Of The CTL Line:

Hydraulic Decoiler -- Feeder Device -- Straightener Machine -- Transition Bridge -- Servo Feeding -- High Speed Shearing Machine -- Conveyor Belt -- Stack


Components Detail

Decoiler Unit

This decoiler our sizing unit allows multiple strands of coils to be pre-positioned on the loading station. It is available with a single or double head to suit different requirements.



Leveling Machine

Our cut to length line straightener can have different designs from 2H, 4H or 6H. It can be flexibly controlled for good leveling of the sheet.

Its leveling rolls are made of roll steel with chrome plated surface. It has good wear resistance and long service life.


Feeder Roller

KINGREAL CTL Line use one or two pairs of feeding rollers, driven by AC servo motors, to feed the strip to the set length precisely.

They ensure fast positioning with minimal errors. These feed rollers are compatible with hydraulic shears or pneumatic clutch shears for fast cutting and easy gap adjustment.

They can be equipped with roller or belt conveyors.

Advantage Of Light Gauge Cut To Length Production Line

High Precision Processing

KINGREAL Light Gauge Cut To Length Line adopts advanced processing components and has a professional casting team to ensure the quality of the production line. Realize the complex processing of various materials and the degree of precision in the processing process.



Automation Technology

Using advanced controllers, automatic control can be realized, which improves the processing accuracy and reliability.



Adjustability

The CTL Line can adjust the parameters of the production line according to the needs of customers to meet the needs of different customers; such as different production speeds and widths of cut-to-length plates.


Specification Of The CTL Line

Thickness(mm)

Width (mm)

Weight(Ton)

Max sheet length (mm)

0.2-2

100 - 750/1250/1600

10

1000/ 2500/3000

0.3-3

500 - 1250/1600

15

500-4000

0.5-4

500 - 1250/1600

15

500-4000

1-6

600 - 1250/1600

20

500-6000

2-8

600-1250/1600/2000

25

500-8000

3-10

600-1250/1600/2000

25

1000-12000

4-12

600-1250/1600/2000

25

1000-12000

Product Display

FAQ:

I am new to this field and do not know enough about the machine to operate it?

This machine has been installed and tested before delivery. It is very easy to operate.

Usually, our customers can operate the machine well if they follow the instructions.

If necessary, we can also send a technician to your factory to repair the machine and train your staff.



What kind of delivery method do you have?

After we receive the deposit, we will arrange the production. The delivery will be done in about 30 working days.



Can a machine produce only one size?

Not exactly, it depends on the machine.



What can you do if the machine breaks down?

Our machines have a 12-month warranty. If the faulty part cannot be repaired, we can send you a new part to replace the faulty one, but you have to pay the courier cost yourself. If the warranty period has expired, we can negotiate a solution and provide technical support for the entire life of the machine.
