KINGREAL STEEL SLITTER Stainless Steel Coil Slitting Machines are used to slit a variety of metal materials, including aluminum, stainless steel, steel, hot-rolled, cold-rolled, and PPGI, from wide coils into narrow strips. These Stainless Steel Coil Slitting Machines unwind, slit the metal, and then recoil the slit metal sheets. The Stainless Steel Coil Slitting Machine operates at a maximum speed of 220 m/min.
Video About Stainless Steel Coil Slitting Machine
Stainless Steel Coil Slitting Machine Description
KINGREAL STEEL SLITTER stainless steel coil slitting machine can divide the stainless steel material coil into strips of the same width according to the needs of customers, and then roll them up.
KINGREAL STEEL SLITTER have the rich produce experience in stainless steel coil slitting line, can ensure the precision and high-speed production efficiency of the stainless steel coil slitting machine.
The stainless steel coil slitting machine can accurately slit the stainless steel coil into different widths, the high-quality production parts and sharp cutting tools are critical to production results.
Production Process Of Stainless Steel Coil Slitting Line
Hydraulic Coil Car -- Hydraulic Decoiler -- Pinch Leveler Shear -- Front loop&Bridge -- High Speed Slitting Machine-- Rear loop Pit & Bridge -- Sheet Transmission Belt-- Recoiler
Main Part Details Of Stainless Steel Coil Slitting Machine
● Single cantilever structure bearing capacity: 12 Tons.
● Macimum Support: 500mm.
● Decoiler Method: hydraulic tension.
● Electric unwinding power: 7.5KW frequency conversion.
● Hydraulic pump: 4Kw.
● For materials with a weight of up to 12 tons, KINGREAL has designed an uncoiling trolley, which can complete the work of rewinding.
● Slitting parts are the most important part of the whole stainless steel coil slitting machine, the quality of which directly determines the quality of slitting.
● KINGREAL STEEL SLITTER adopts Cr12Mov materials to produce the slitting blade, which thickness is 10mm.
Stainless Steel Coil Slitting Line Specifications:
|
Material |
Stainless Steel Or Other |
|
Thickness Range |
0.3-2.5mm |
|
Width Range |
500-1800mm |
|
O.D. |
≤φ2000mm |
|
MaximumSlitting Speed |
220m/min |
|
Maximum Slit |
35pcs |
|
Maximum Belt Speed |
20m/min |
|
Capacity |
258KW |
Stainless Steel Recoiler Product Specifications
|
Max Coil Weight |
15T |
|
Min Slitted Width |
21mm |
|
Max slitted Strip |
20 |
|
Accuracy |
≤0.05mm |
|
Burs |
≤0.03mm |
KINGREAL STEEL SLITTER stainless steel coil slitting machines are designed and manufactured with meticulous attention to detail, ensuring they can produce narrow strips of extremely precise products. The stainless steel coil slitting machine is equipped with slitting blades made of DC53 die steel, a material with excellent wear resistance and strength, ensuring they maintain sharpness and cutting accuracy over long periods of use. Furthermore, the stainless steel coil slitting machine features twin slitters, enabling quick blade changes in just 20 seconds, significantly improving production efficiency and reducing downtime associated with tool changes.
In the stainless steel coil slitting machine's internal structure, KINGREAL STEEL SLITTER utilizes iron-core rubber washers, which not only effectively reduce vibration but also provide greater stability during the cutting process, further enhancing cutting accuracy. To ensure efficient cutting performance even under high loads, KINGREAL STEEL SLITTER also uses high-quality Cr12MoV forming rollers. These forming rollers not only offer excellent wear resistance but also ensure consistent shape and size of the metal material during the slitting process, preventing deformation or errors. After the stainless steel coil slitting machine is manufactured, KINGREAL STEEL SLITTER will invite the customer to the KINGREAL STEEL SLITTER factory for joint testing. KINGREAL STEEL SLITTER staff will conduct various tests on the stainless steel coil slitting machine's components, including visual and operational testing, to ensure that the stainless steel coil slitting machine's performance and parameters fully meet the customer's production requirements. During the testing process, the customer can directly observe the stainless steel coil slitting machine's operation and provide feedback and suggestions, ensuring that every detail meets the expected standards.
Only after confirming that the stainless steel coil slitting machine's performance matches the promised performance in the customer's customized manufacturing plan will KINGREAL STEEL SLITTER package and ship the stainless steel coil slitting machine. If any discrepancies are found during testing, KINGREAL STEEL SLITTER engineers will promptly perform adjustments to ensure that every performance feature of the stainless steel coil slitting machine meets the customer's requirements.
Final Product Display
Why choose Us？
√ Extensive project production experience (up to 20+ years)
√ Diversified technical design support (to meet customer customization needs)
√ Machine manufacturing quality assurance (ISO CE certified)
√ Installation after-sales service
FAQ
Yes, KINGREAL STEEL SLITTER are a stainless steel coil slitting machine manufacturer. KINGREAL STEEL SLITTER have a factory and our own technical team, feel free to visit us.
1. Thickness of the coil (min-max)?
2. Coil width (min-max)?
3. What is your steel material?
4. Coil weight (max)?
5. How many pieces of maximum thickness do you need to slit?
6. How many tons do you need per day or per month?
KINGREAL STEEL SLITTER factory is located in Foshan city, Guangdong Province. So there are two ways to our city.
One is by flight, direct to Foshan or Guangzhou Airport. Another is by train, direct to Foshan or Guangzhou station.
KINGREAL STEEL SLITTER will pick you up at the station or airport.
KINGREAL STEEL SLITTER have specialized in this industry for over 20 years, especially in metal coil slitting machines.
KINGREAL STEEL SLITTER stainless steel coil slitting machines are exported directly to Russia, Vietnam, India, Indonesia and many other countries in Asia, Africa, Middle East and South America.
After-Sale Service
In order to help our customers to solve stainless steel coil slitting machine installation problems, KINGREAL STEEL SLITTER will provide both online and local installation services.
Online installation guide
- Photos and videos of stainless steel coil slitting machine will be sent
- Online group will be initiated to discuss together
- Regular video conference be held to keep communication and contacting
Local installationKINGREAL STEEL SLITTER will arrange engineers to go abroad to install the stainless steel coil slitting machine at the customer's place to ensure the normal operation of the stainless steel coil slitting machine, and will provide all technical guidance. Exact costs to be negotiated.
KINGREAL STEEL SLITTER Engineers Support
KINGREAL STEEL SLITTER is able to provide technical after-sales service to our customers.
In order to ensure the smooth installation and operation of the stainless steel coil slitting machines, KINGREAL STEEL SLITTER will arrange to send engineers to the customer's project for technical guidance.
Up to now, KINGREAL STEEL SLITTER has helped customers from Russia, Mexico, India and Saudi Arabia to use the stainless steel coil slitting machines smoothly.
